| 制造商: | Bird |
| Model: | 3-A-MFB-K1 |
Power Rating: 3 W
Connector: SMA
VSWR and Frequency Range:
1.10:1 from DC to 1 GHz
1.25:1 from 1 to 4 GHz
Impedance: 50 Ohm
Temperature: -40 to 40 °C (-40 to 104 °F)
PIM: -110 dBc Min.
AC Power: None
Humidity: 95% non-condensing
Standard Attenuation Values: 3, 6, 10, 20 dB
Dimensions: 6.50" x 1.69" x 4.63"/ (165.1 x 42.93 x 117.6 mm)
Weight: 8 oz./227 g
Finish: TRi Alloy
