METONE PARTAC パーティクルカウンター (0.3~10µm; 8 channels)

Operating Principle: Counts individual airborne particles utilizing scattered laser light.

Particle Size Range: 8 Channels, programmable in the range 0.3~10µm

Concentration Range: 0~9000000 particles per cubic foot (317700 particles/L)

Accuracy: ±10%, to calibration aerosol

Sensitivity: 0.3um at 2 to 1 peak to valley, 2 to 1 SIN

Flow Rate: 1LPM

Sample Time: 1 second to 1 hour

Calibration Standards: Factory calibrated in accordance with ASTM F328 and ASTM F649.

Light Source: Laser Diode, 35mW, 780nm

Power:

• 6~15V DC ( 12V DC with flow system )

• Average: 140mA (400mA with flow system)

• Max: 190mA (450mA with flow system)

Certifications: Meets or exceeds CE, ISO, ASTM and JIS international certifications

Communication:

• Standards: RS-232C full duplex or RS-485 selectable full or half duplex

• Protocol: Serial (comma delimited ASCII) or MODBUS RTU

Settings:

• 9600 Baud rate, 8 Data Bits, No Parity, 1 Stop Bit, No Flow Control

• Built-in MODBUS registers for laser life time, laser fault, pump life time, pump fault, & filter fault detection.

Size: Length: 10.5" (26.7cm); Diameter: 4.00" (10.2cm)

Weight: 4.0Ib (1.8kg)

Operating Temperature: -10~60°C

Storage Temperature: 40~80°C
