EAST TESTER ET3242 デジタルベンチトップマルチメータ (55000(4 4/5) digits)

Technical indicators

- Display screen: 3.5” TFT LCD (resolution of 320*480)

- Number of display digits: 55000(4 4/5)

- Display rate: Slow: 2 seconds per second; Medium: 5 times per second; Fast: 7 times per second

- Measuring range:

+ DCV: 10μV~1100V

+ DCI: 10nA~12A

+ ACV: 10μV~800V

+ ACI: 10nA~12A

+ Resistance: 10mΩ~1GΩ

+ Capacitance: 1pF~10mF

+ Frequency: 1Hz~20MHz

General technical specifications

- Power supply voltage: 220V AC ± 10%, 110V AC ±10%, 45-65Hz;

- Display: 3.5 inch TFT LCD screen, resolution 480x320, color 16M;

- Operating Temperature: 0~40 ℃;

- Storage environment: - 10~50 ℃;

-  Relative humidity <80%;

- Interface: ET124X Standard - USB Device, ET125X Standard - USB Device, RS232, other optional - GPIB, USB Host, LAN, Wifi, Bluetooth;

- Shape size: 265 mm * 105 mm * 305 mm (width * height * depth);

- Weight: 2.3kg

Standard accessories

- Three core power cord*1(30A51)

- Three core pen*1(32A52)

- Backup power fuse*2(32A52)

Optional accessories

- GPIB cable

- Cabinet installation kit

- Rs232 serial port line

- USB data line
