THORLABS YDFA100P Ytterbium-Doped Fiber Amplifiers (Polarization Maintaining)
Manufacturer: THORLABS Model: YDFA100P - Request a Quotation
- Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Amplifier Specifications
Operating Wavelength Range: 1025 - 1075 nm
Output Power (@ 3 dBm Input Power)(a): 19 dBm (Min) 20 dBm (Typical)
Small Signal Gain (@ -20 dBm Input Power)(a): >22 dB
Noise Figure (a): <8 dB
Output Power Stability (@ 3 dBm Input Power): <±2% Over 24 Hours(After 15 Minute Warm-Up, for Ambient Temperature ±2°C)
Total Absolute Dispersion within Amplifier: <0.2 ps/nm
Laser Class: 3B
Fiber Specifications
Output Polarization: Linear Aligned to Slow Axis
Polarization Extinction Ratio: >20 dB
Polarization-Dependent Gain: N/A
Return Loss at Input Port: > 50 dB
Input / Output Isolation: >20 dB
Input / Output Fiber Type: PM980-XP
Input / Output Fiber Connectors: FC/APC Compatible, 2.0 mm Narrow Key
(a) Please refer to the manual for the variation of each parameter over a range of wavelengths and input powers.
