MKS DC1340 定向耦合器 (Single Channel; 2450MHz)

VSWR: 1.25 max

Directivity: 25 dB

Flange Type: R 26 (IEC 153)

Maximum Power: 6 kW

Coupling Factor: 60 dB ±1 dB

Output Connector: N female (standard) SMA-F on request

Waveguide Size: WR340

Operating Frequency: 2450MHz, ±25MHz

Number of Channels: 1

Dimensions: 100 x 99mm

Weight: 0.9 kg
