Leadfluid BT300S 基本变速蠕动泵 (0.006~1300mL / min, 1 CH)

Specifications

Flow range: 0.006~1300 mL/min

Speed range: 0.1-350rpm

Speed accuracy: 0.2%

Speed resolution: between 0.1-100 rpm, 0.1 rpm resolution; between 100-350 rpm, 1 rpm resolution

Power supply: AC 100-240V, 50Hz/60Hz

Power consumption: < 50W

External logic level control signal: 5V, 12V (standard), 24V (optional)

External analog control signal: 0-5V (standard); 0-10V, 4-20mA (optional)

External communication interface: MODBUS RS485

Ambient temperature: 0-40 °C

Relative humidity: < 80%

IP grade: IP31

Dimension (L x W x H): 264 x 150 x 270 mm (10.39 x 5.91 x 10.63 inch)

Weight: 4.9 kg (10.8 lbs)

Details

BT300S Suitable Pump Heads and Tubing, Flow Parameters

Drive typePump headch    Tubing size (mm)Flow rate per channel (mL/min)
BT300SYZ15113# 14# 16# 19# 25# 17#18#          0.006-1340
YZ25115# 24#35#36#          0.17-990
2 x YZ15213# 14# 16# 19# 25# 17#18#          0.006-1340
2 x YZ25215# 24#35#36#          0.17-990
DT15-24219# 16# 25# 17#          0.07-1300
YT15113# 14# 16# 19# 25# 17# 18#         0.006-1340
YT25115# 24# 35# 36#         0.17-1690
2 x YT15213# 14# 16# 19# 25# 17# 18#         0.006-1340

Above flow parameters are obtained by using silicone tube to transfer pure water under normal temperature and pressure, in actually it is effected by specific factors such as pressure, medium, etc. Above for reference only.
