Leadfluid BT100F-1 智能点胶蠕动泵 (0.006-570mL/min, 2 CH)

Flow range: 0.006-570 mL/min

Speed range: 0.1-150 rpm

Speed resolution: 0.1 rpm

Flow accuracy: 0.2%

Power supply: AC 10-240V, 50Hz/60Hz

Power consumption: < 60W

External logic level control signal: 5V, 12V (standard), 24V (optional)

External analog control signal: 0-5V (standard), 0-10V, 4-20mA (optional)

Communication interface: MODBUS RS485

Operating condition: 0~40 °C

Relative humidity: < 80%

IP grade: IP31

Dimensions (L x W x H): 278mm × 150mm × 237mm (10.94 inch x 5.91 inch x 9.33 inch)

Weight: 4.7 kg (10.36 lbs)

Details

BT100F-1 Suitable Pump Heads and Tubing, Flow Parameters

Drive typePump headChTubing size (mm)Flow rate per channel (mL/min)
BT100F-1DG6-8 (6rollers)8Wall:0.8~1, ID:≤3.170.0002-49
DG10-8 (10rollers)8Wall:0.8~1, ID:≤3.170.0001-41
DG6-12 (6rollers)12Wall:0.8~1, ID:≤3.170.0002-49
DG10-12 (10rollers)12Wall:0.8~1, ID:≤3.170.0001-41
DG6-16 (6rollers)16Wall:0.8~1, ID:≤3.170.0002-49
DG10-16 (10rollers)16Wall:0.8~1, ID:≤3.170.0001-41
DG6-24 (6rollers)24Wall:0.8~1, ID:≤3.170.0002-49
DG10-24 (10rollers)24Wall:0.8~1, ID:≤3.170.0001-41
DT10-88813# 14#, Wall:0.8~1, ID:≤3.170.0002-82
YZ15113# 14# 16# 19# 25# 17#0.006-420
YZ25115# 24#0.16-420
2 x YZ15213# 14# 16# 19# 25# 17#0.006-420
2 x YZ25215# 24#0.16-420
YT15113# 14# 16# 19# 25# 17# 18#0.006-570
YT25115# 24# 35# 36#0.16-720
2 x YT15213# 14# 16# 19# 25# 17# 18#0.006-570
2 x YT25215# 24# 35# 36#0.16-720
DT15-14116# 19# 25# 17#0.07-560
DT15-24216# 19# 25# 17#0.07-560
DT15-44416# 19# 25#0.07-330
KZ25115# 24# 35# 36#0.25-1200
DMD25115# 24# 35# 36#0.3-1700

Above flow parameters are obtained by using silicone tube to transfer pure water under normal temperature and pressure, in actually it is effected by specific factors such as pressure, medium, etc. Above for reference only.
