JCW JCW-F16 伺服型自动鞋带套线压接机 (6-30 mm, 20 mm)

Function: Single wire, Multicore cable, Wire end stripping, Conductor twisting, Tubular insulated terminal crimping, Quadrangle crimping, Stripping length, Cutting depth, Data library

Conductor cross-section: 0.3, 0.5, 0.75, 1.0, 1.5, 2.5, 4.0, 6.0, 10, 16 mm² [adjusting vibrate bowl]

Stripping length: 6-30 mm

Crimping profile: Quadrilateral [imitating square]

Crimping length: Max 20 mm

Cycle time: 3.2 seconds

Display: 7" color touchscreen, English / Chinese [other languages on request]

Customize logo: Yes

Air supply: 0.6 - 0.8 MPa (clean and dry air)

Rated power: 1500 W

Power supply: AC 220V ± 10%, 10A, 50/60 Hz

Dimensions: L 365 x W 522 x H 430 mm

Weight: 65 KG

Details

Datasheet
