THORLABS C-FIBER HIGH POWER Femtosecond Fiber Laser

Center Wavelength: 1560 nm ± 20 nm

Average Power: >500 mW

Pulse Energy: >5 nJ

Pulse Width: <90 fs

Repetition Rate: 100 MHz (50-250 MHz with VARIO)*

Repetition Rate Instability: <1 ppm over 20 hours at constant temperature

Timing Jitter: <2 fs [rms, 10 kHz.. 10 MHz]

Output Port: free space

Additional Fiber-Coupled Seed Port: 1 (up to 4 with MULTIBRANCH)

Polarization: linear, s-polarized

Beam Height: 102 mm

Details

Manual
